TBM-1410 series
Tiny-Bus PCIe
ExpressCard
Module
Supports
ExpressCard/34, ExpressCard/54
and Mini-PCI Type-IIIA/B Socket |
 |
|
|
Key Features :
The TBM-1410 is a Tiny-Bus® PCIe
(PCI Express) based ExpressCard module offers the
ExpressCard/34, ExpressCard/54 and one mini-PCI interfaces for
the industrial small form factor (SFF) embedded x86-based
computing applications.
-
PCMCIA ExpressCard standard.
-
Supports ExpressCard/34 and
ExpressCard/54 add-on cards.
-
One mini-PCI type-III A/B socket.
-
Liantec embedded Tiny-Bus®
Modular Expansion Solution.
|
Gallery
TBM-1410 Sample Enquiry |
|
|
|
|
|
General Specification
►
Tiny-Bus® Modular Expansion Solution with PCI Express
and PCI bus
interface.
►
Supports PCMCIA ExpressCard/34 and ExpressCard/54
modules.
►
Onboard Mini-PCI type-IIIA/B socket.
External / Internal
Connector
►
External ExpressCard connector.
►
Onboard Mini-PCI type-IIIA/B
socket. |
|
|
 |
|
|
|
|
|
|
|
|
|
